W-600A: 24" W-Series Automatic Impulse Sealer w/ 2.7mm Seal Width W-600A: 24" W-Series Automatic Impulse Sealer w/ 2.7mm Seal Width

50 in stock

$685.00

W-Series automatic sealers are designed for the continuous sealing of thermoplastic materials.    The W-600A is equipped to seal materials up...

W-Series automatic sealers are designed for the continuous sealing of thermoplastic materials.    The W-600A is equipped to seal materials up to 24" wide and 10mil total thickness.  Equipped with an electronic timer and electromagnet, once correct settings have been established, consistent seals will be maintained automatically.

FEATURES:

  • Automatic impulse sealing with precise electronic control
  • Dual mode operation: automatic or manual
  • Foot switch allows both hands to be free
  • 3 separate control settings for sealing time, recycle time, and congealing time to produce consistent seals
  • Includes electric foot switch and worktable
  • Seal Length: 24" / 600mm
  • Seal Width: 2.7mm

The manufacturer's replacement kit includes 2 heating elements.

Easy to operate.

For automatic operation, set the control on auto.  Adjust the sealing time (heating time), congealing time (cooling time), and recycle time (automatic operation of jaws).  Insert material to be sealed and when jaw opens, remove sealed material.

For manual operation, set the control to manual.  Insert the material to be sealed. Press down on the foot switch to activate the sealing bar.

Model #

Seal Length

Seal Width

Thickness

Power

Weight

Dimensions

W-300A

12"

2.7MM

10MM

450W

50LBS

17” x 14” x 8”

W-305A

12"

5MM

15MM

600W

52LBS

17” x 14” x 8”

W-3010A

12"

10MM

20MM

1000W

55LBS

17” x 14” x 8”

W-450A

18"

2.7MM

10MM

600W

56LBS

21" x 14" x 8"

W-455A

18"

5MM

15MM

800W

59LBS

21" x 14" x 8"

W-600A

24"

2.7MM

10MM

800W

68LBS

27" x 14" x 8"

W-605A

24"

5MM

15MM

1300W

70LBS

27" x 14" x 8"

W-755AA

30"

5MM

15MM

1200W

82LBS

33" x 14" x 10"
